The Impact of Character Sets on Teradata SQL Performance: A Case Study
As a Teradata SQL specialist, I find skew to be a common challenge. In fact, approximately 90% of SQL performance difficulties stem from skew, based on my experience. However, this article focuses on the potential for minor modifications to yield significant improvements.
This article highlights the potential consequences of selecting inappropriate character sets for SQL performance, a commonly neglected aspect.
How it all began
While reviewing the QryLog table, I noticed a DELETE statement that was significantly impacting CPU usage and resulting in excessive IO operations. In fact, this statement caused more IOs than any other daily workload.
Want more practical data engineering analysis like this?
Join DWHPro Letters and get field-tested notes on Teradata, Snowflake, AI, migrations, performance, and enterprise data work. Early subscribers keep launch access before the paid plan launches.
Moreover, resource usage appeared to be escalating rapidly. The chart below demonstrates that an average of 50 million rows were added daily.
The DELETE statement is executed on a massive table named "TheTable" with nearly 3 billion records. A subquery is utilized to identify the specific rows for deletion, with the table "TheVolatileTable" used for filtering, containing only one row.
Below you can see the table definitions of both involved tables:
SELECT CAST(COUNT() AS BIGINT) FROM TheDatabase. TheTable;
Count()
2.928.780.765 --> almost 3 billion rows!
This table filters the rows to be deleted and contains only one row.
SELECT COUNT() FROM TheVolatileTable;
Count() 1 --> exactly 1 row
The Initial Situation
The volatile table is created using this syntax in the initial setup:
CREATE TABLE AS (<SUBQUERY>);Creating and populating tables in a single step is a convenient approach. However, the query's author overlooked the significance of data types and character sets. Character columns on the affected Teradata system are generated with the UNICODE character set by default. Regrettably, the table "TheTable" specifies these character columns as a LATIN character set, resulting in a mismatch.
CREATE MULTISET VOLATILE TABLE TheVolatileTable
(
Col1 VARCHAR(3) CHARACTER SET UNICODE NOT CASESPECIFIC,
Col2 VARCHAR(1) CHARACTER SET UNICODE NOT CASESPECIFIC,
Col3 DATE FORMAT 'YYYY-MM-DD',
Col4 CHAR(12) CHARACTER SET UNICODE NOT CASESPECIFIC)
NO PRIMARY INDEX ON COMMIT PRESERVE ROWS;
The DELETE statement's execution plan for poor performance appears as follows:
-
First, we lock a distinct TheDatabase."pseudo table" for write
on a RowHash to prevent global deadlock for
TheDatabase. TheTable. -
Next, we lock TheDatabase. TheTable for write.
-
We execute the following steps in parallel.
1) We do an all-AMPs RETRIEVE step from
TheDatabase. TheTable by way of an all-rows scan
with no residual conditions into Spool 2 (all_amps)
(compressed columns allowed) fanned out into 50 hash join
partitions, which is built locally on the AMPs. The size of
Spool 2 is estimated with high confidence to be 2,928,780,765
rows (123,008,792,130 bytes). The estimated time for this
step is 32.77 seconds. -
We do an all-AMPs RETRIEVE step from
TheVolatileTable by way of an all-rows scan with no
residual conditions into Spool 4 (all_amps), which is
redistributed by the hash code of (
TheVolatileTable. COL4,
TheVolatileTable. COL3,
TheVolatileTable. COL2,
TheVolatileTable. COL1) to all AMPs. Then
we do a SORT to order Spool 4 by the sort key in spool field1
eliminating duplicate rows. The size of Spool 4 is estimated
with high confidence to be 2 rows (186 bytes). The estimated
time for this step is 0.02 seconds. -
We do an all-AMPs RETRIEVE step from Spool 4 (Last Use) by way of
an all-rows scan into Spool 3 (all_amps) (compressed columns
allowed) fanned out into 50 hash join partitions, which is
duplicated on all AMPs. The size of Spool 3 is estimated with
high confidence to be 780 rows (72,540 bytes). -
We do an all-AMPs JOIN step from Spool 2 (Last Use) by way of an
all-rows scan, which is joined to Spool 3 (Last Use) by way of an
all-rows scan. Spool 2 and Spool 3 are joined using a inclusion
hash join of 50 partitions, with a join condition of (
"((TRANSLATE((COL1)USING LATIN_TO_UNICODE))=
COL1) AND (((TRANSLATE((COL2)USING
LATIN_TO_UNICODE))= COL2) AND ((COL3 = COL3) AND
((TRANSLATE((COL4)USING LATIN_TO_UNICODE))= COL4)))").
The result goes into Spool 1 (all_amps), which is redistributed by
the rowkey of (TheDatabase. TheTable. ROWID) to all
AMPs. Then we do a SORT to partition Spool 1 by rowkey and the
sort key in spool field1 eliminating duplicate rows. The size of
Spool 1 is estimated with low confidence to be 12,253 rows (
220,554 bytes). The estimated time for this step is 0.50 seconds. -
We do an all-AMPs MERGE DELETE to
TheDatabase. TheTable from Spool 1 (Last Use) via the
row id. The size is estimated with low confidence to be 12,253
rows. The estimated time for this step is 1.87 seconds. -
Finally, we send out an END TRANSACTION step to all AMPs involved
in processing the request.
-> No rows are returned to the user as the result of statement 1.
The execution plan has multiple issues. Primarily, the join columns in the large table "TheTable" necessitate conversion from LATIN to UNICODE. This conversion must be performed for every row, totaling 3 billion times.
This operation is costly in terms of CPU usage.
Moreover, the large table is partitioned into 50 hash partitions to facilitate the sequential join. Spooling this table with billions of rows requires considerable resources — an approach forced by the need to handle the character set conversion.
Below you can see the amount of IOs and CPU seconds being used:
| TotalIOCount | AMPCPUTime | SpoolUsage |
| 3.585.081.549,00 | 71.510,38 | 1.397.760,00 |
The Tuning Approach
The query tuning was straightforward yet impactful. I generated the volatile table manually and selected the LATIN character set to align with the character sets in both tables.
You can view the enhanced execution plan below.
1) First, we lock a distinct TheDatabase."pseudo table" for write on a RowHash to prevent global deadlock for TheDatabase. TheTable.
2) Next, we lock TheDatabase. TheTable for write.
3) We do an all-AMPs RETRIEVE step from TheVolatileTable by way of an all-rows scan with no residual conditions into Spool 3 (all_amps), which is built locally on the AMPs. Then we do a SORT to order Spool 3 by the sort key in spool field1 ( TheVolatileTable. Col1, TheVolatileTable. Col2, TheVolatileTable. Col3, TheVolatileTable. Col4) eliminating duplicate rows. The size of Spool 3 is estimated with high confidence to be 2 rows (124 bytes). The estimated time for this step is 0.02 seconds.
4) We do an all-AMPs RETRIEVE step from Spool 3 (Last Use) by way of an all-rows scan into Spool 2 (all_amps) (compressed columns allowed), which is duplicated on all AMPs. The size of Spool 2 is estimated with high confidence to be 780 rows (48,360 bytes).
5) We do an all-AMPs JOIN step from TheDatabase. TheTable by way of an all-rows scan with no residual conditions, which is joined to Spool 2 (Last Use) by way of an all-rows scan. TheDatabase. TheTable and Spool 2 are joined using a inclusion dynamic hash join, with a join condition of ( "(TheDatabase. TheTable. Col1 = Col1) AND ((TheDatabase. TheTable. Col2 = Col2) AND ((TheDatabase. TheTable. Col3 = Col3) AND (TheDatabase. TheTable. Col4 =Col4)))"). The result goes into Spool 1 (all_amps), which is built locally on the AMPs. Then we do a SORT to partition Spool 1 by rowkey and the sort key in spool field1, eliminating duplicate rows. The size of Spool 1 is estimated with low confidence to be 12,253 rows (220,554 bytes). The estimated time for this step is 13.06 seconds.
6) We do an all-AMPs MERGE DELETE to TheDatabase. TheTable from Spool 1 (Last Use) via the row id. The size is estimated with low confidence to be 12,253 rows. The estimated time for this step is 1.87 seconds.
7) Finally, we send out an END TRANSACTION step to all AMPs involved in processing the request.
-> No rows are returned to the user as the result of statement 1.
The enhanced execution plan utilizes dynamic hash joins, which do not require spooling the 3 billion rows. Instead of spooling to rehash join columns, the Teradata Optimizer calculates the row hash "on the fly" for each row.
This minor adjustment significantly decreased resource consumption.
| IO Count | CPU Time | SpoolUsage | |
| Tuned | 1.335.246,00 | 2.916,23 | 599.040,00 |
| Original | 3.585.081.549,00 | 71.510,38 | 1.397.760,00 |
| Reduced to: | 0,04% | 4,08% | 42,86% |
Impressive statistics show a drastic decrease in IOs by 99.96%, CPU seconds by approximately 96%, and a 50% reduction in spool usage.
This successful tuning demonstrates the possibility of making significant enhancements with minimal effort. It is imperative to identify and prioritize the optimization of your most problematic workload. Consequently, improving your most inefficient queries should be among your primary objectives.
